The J3-64

A 60 by 40 degree arrayable 140 dB Box!

j3-64 header image

A 60 by 40 degree arrayable 140 dB Box!

Specifications

  • coverage Pattern
    60 by 40
  • operating
    frequency range
    43 Hz - 20 kHz
  • continuous output
    Band dependent, 150 dB SPL
  • peak output
    Band dependent >150 dB SPL
  • sensitivity
    112 dB SPL average, (2.38 volts into rated Z at 1 meter)
  • driver complement
    Six 15" woofers
    eight 6.5"mids
    High/Mid & High, four Coaxial compression drivers
  • dimensions
    30 X 35.6 X 48 inches
  • weight
    432 Lbs
  • Rated Impedance
    Low Freq, Two 3 ohm loads
    MId range a single 4 ohm load
    High, a single 4 ohm load
